Automatic Super High Speed Self Adhesive (Sticker) Ampoules and Vials Labelling Machines with Camera Based Inspection and Rejection System. Models: AHL-450ASA-R and AHL-600ASA-R
Automatic Super High Speed Self Adhesive (Sticker) Ampoules and Vials Labelling Machines with Camera Based Inspection and Rejection System. Models: AHL-450ASA-R and AHL-600ASA-R
These machines are 100% servo based equipped with advance motion controller technology capable to deliver higher output varying from 450 to 600 Vials/Ampoules per minute depending upon its size and label size.
labeling operation is done in rotary motion where vials/ampoules are held by starwheels for proper gripping and smooth traveling thereby giving excellent labelling accuracy with minimum breakage. Customer can additionally buy:
5. FDA 21 CFR Part 11 compliance with high end industrial touch screen and PC
Product Details
Technical Specifications
24,000 – 27,000 (Depends upon Container size & label size)
Vial - 2 ml to 10 ml
Ampoules - 1 ml to 20 ml
Length - 20 mm to 80 mm
Width - 10 mm to 60 mm
2950 mm (L) X 1850mm (W) X 1900 mm (H) (Approx.)
33,000 – 36,000 (Depends upon Container size & label size)
Vial - 2 ml
Ampoules - 1 ml to 20 ml
Length - 20 mm to 80 mm
Width - 10 mm to 60 mm
2950 mm (L) X 1850mm (W) X 1900 mm (H) (Approx.)
Salient Features
- Advanced multi axis servo driven machine
- Machine with rejection and container rejection verification system
- No label - Container rejection system
- Lockable rejection bin
- Most rigid machine construction ensures vibration free and smooth operation
- New user friendly interface on touch screen
- Smooth label dispensing
- Double label dispense prevention due to missing label on roll
- “No vial/ampoule – No label” – an electro – sensing device avoids wastage of labels
- Servo drive for label dispensing unit
- An inbuilt digital counter provides continuous information of labeled containers on screen
- An inbuilt real – time speed indicator will show actual speed of machine
- An inbuilt PLC and Touch Screen HMI for control and operation of machine with advance software
- Machine equipped with basic level 21 CFR features like user management and audit trails
- Label roll end – Machine stop system
- Vials max dia. upto 25mm and cap dia. should be smaller than body dia. of vials
Optional Accessories
- Inkjet printer to print batch details on labels
- Advance camera to inspect the printed batch details
- Computer system with SS stand to teach camera the parameters to inspect on labels
- Rejection mechanism to reject the container in case of no label on container, no printing on label and faulty printing on label
- Web rejection system to reject label with faulty printing or no printing prior label application on container
- FDA 21 CFR Part 11 compliance with high end industrial touch screen and PC
- UPS for PLC, camera and PC
